Case studies

Work we have delivered

Engagements carried from schematic through firmware to a unit that could be built. Client names are withheld; the engineering is described as it was done.

Discuss a project
Delivered XceedMinds hardware on a test bench — a bare development board, the same design in a sealed enclosure with M12 and Ethernet connectors, and a finished rack-style unit with status indicators, alongside a schematic print, a layout plot, an oscilloscope and a bench supply

Selected work

Different problems, one way of working

Mains-powered industrial acquisition, battery-scale wireless, precision signal generation, on-device sensor fusion. Each carried end to end by one team.

  1. 01Railway infrastructure

    Turn-key IoT platform for trackside monitoring and data logging

    Eight-channel analog acquisition, optically isolated safety monitoring and a custom LoRa-to-Linux bridge on a single 110V AC board.

    • LoRa P2P
    • WLR089U0-I/RM
    • 4-20mA
    • Optical isolation
    • 110V AC
  2. 02Railway infrastructure

    Connected LED signal marker board for railway applications

    Redundant LED strings that degrade rather than go dark, with carrier-independent LTE-M/NB-IoT, GNSS tracking and over-the-air updates on a battery budget.

    • STM32L431
    • LTE-M / NB-IoT
    • eSIM multi-operator
    • GNSS
    • OTA updates
  3. 03Signalling & test equipment

    Turn-key design of a precision 56 kHz loop signal generator

    Three signalling frequencies held to ±0.01% with sub-5ms switching, dual waveform output, and a 50Ω output stage driven from 24V DC.

    • AD9833 DDS
    • STM32L431
    • ±0.01% accuracy
    • < 5 ms switching
    • PWM & analog gain
  4. 04Wearables & connected devices

    Embedded IoT platform for sensor fusion and haptic alerting

    Motion and load data fused on-device so feedback happens in milliseconds, not after a cloud round trip — on a wearable-scale power budget.

    • Nordic nRF52833
    • Zephyr RTOS
    • nRF Connect SDK
    • BLE 5 / GATT
    • Load cell + INA

Domains

Where this work has been deployed

Industries with delivered projects behind them, rather than a longer list of aspirations.

Railway infrastructure

Trackside monitoring, signalling equipment and work-zone safety hardware built for vibration, temperature and unattended operation.

Industrial monitoring

Multi-channel analog acquisition, isolated field inputs and long-range data logging on mains-powered plant equipment.

Signalling & test equipment

Precision frequency synthesis and instrument-grade output stages where accuracy and switching timing carry the information.

Wearables & connected devices

Battery-scale platforms fusing multiple sensor modalities with on-device decisions and continuous wireless links.

Your problem is probably not on this list

These are the ones we can talk about. Describe what you are building and we will tell you honestly whether it is work we have done before, or work we would be learning on.
